Pressure Sensor Pressure Sensor Transducer M10 5V to 12V 0.5-4.5 V 0-30 Bar Water Oil Fuel Gas Air Pressure Measuring transdutor de pressão

Product Features

This pressure sensor transducer, with an M10 connection, has a measuring range of 0-300bar gauge pressure and a supply voltage of 5-12VDC. It is CE-certified.
Made in Mainland China, this pressure sensor is suitable for measuring water, oil, fuel, gas, and air pressure.
With an accuracy of ≤±1.0%FS and an operating temperature of-40-105℃, this sensor provides reliable and accurate pressure measurements.
The 304 stainless steel housing and IP65 protection class make this sensor durable and suitable for various industrial applications.
Whether you are in the automotive, manufacturing, or other industries, this pressure sensor will meet your pressure-measuring needs.

Specifications

Brand Name

XIDIBEI

Hign-concerned Chemical

None

Max Measuring Range

200 - 399 Bar

Model Number

XDB401-M4-W7

Measuring range

0-300bar gauge pressure

Supply voltage

5-12VDC

Output signal

0.5-4.5V / 0-5V / 1-5V / I2C / 0.4-2.4V(Low power consumption)

Accuracy

≤±1.0%FS

Operating temperature

-40-105℃

Housing material

304 Stainless Steel

Pressure connection

M10*1

Electrical connection

Direct cable

Protection class

IP65

Explosion-proof class

Exia2CT6

Electromagnetism Compatibility

EN50051-1

semi_Choice

yes

Description

Pressure Sensor Pressure Sensor Transducer M10 5V to 12V 0.5-4.5 V 0-30 Bar Water Oil Fuel Gas Air Pressure Measuring transdutor de pressão
