2.2KW 1.5kw 0.8kw CNC Spindle Motor 110v / 220v 2200W 1500w 800w 400hz Air Cooling Round Spindle 24000RPM For CNC air cooled spindle motor

Product Features

This CNC spindle motor offers 2.2KW, 1.5kw, and 0.8kw power options. With air cooling and a 24000RPM speed, it's suitable for wood and metal milling.
The 400hz frequency of this spindle motor provides high-performance operation. It can work with 110v/220v input voltage, offering flexibility.
Designed for CNC applications, this air-cooled spindle motor has a 4-piece 7002 bearing. It ensures stable and efficient performance during machining.
This spindle motor has different torque values for different power options. The 800W, 1500W, and 2200W models can meet various machining needs.
With its RoHS certification, this CNC spindle motor is environment-friendly and safe to use. It's a reliable choice for industrial and home machining projects.

Specifications

Hign-concerned Chemical

None

Operating Speed

24000

Application

Milling

Drive

MOTOR

product name

Spindle motor 2.2kw 1.5KW 0.8KW

input frequency

50/60hz

application

wood soft metal aluminum acrylic board

bearing

4 pcs 7002

pole

VFD

single phase 220v / 110v

800W spindle diameter

65mm

1500W spindle diameter

80mm

2200W spindle diameter

80mm

800W spindle torque

0.32Nm

1500W spindle torque

0.6Nm

2200W spindle torque

0.88Nm

cooling

Air

frequency

400hz
