Model Number
Colorimeter QS
Spectroscopic methods
Full spectrum LED light source
Full spectrum LED light source
Light filter splitting
Sensors
CMOS dual optical path sensor
Measurement wavelength range
400~700nm
Color space
CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,HunterLab,Bxy,DIN Lab99
The color difference formula
E*ab,E*uv,E*94,E*cmc(2:1),E*cmc(1:1),E*00, DINE99,E(Hunter)
Other chromaticity indexes
Spectral reflectance, WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), metameric index Mt, stain fastness, color fastness, strength, opacity, 555 shades Classification, Munsell(C/2) (implemented by mobile APP)
Illumination
D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30),U35,NBF,ID50,ID65
Display
1.14inch-IPS Color LCD
Stability of measurement
Chromaticity value: E*ab 0.05(After preheating and correction, the average value of the whiteboard is measured for 30 times at an interval of 5s)
Inter-instrument Error
E*00<0.4(BCRA II series 12 color bricks measured average)
Integrating sphere size
20mm
Multi-function smart button
/
Measurement Requirements
passed national measurement
Battery
Lithium battery, can do tests continuously for 12000 times in a single full charge
Illumination source life time
More than 3 million measurementsin5 years
Interface
Type C USB, bluetooth
Store the data
The device has no storage function and can be stored through the mobile APP
Language
Chinese, English
Operating temperature range
0~40℃, 0~85%RH(No condensation),Altitude: lower than 2000m
Temperature range
-20~50℃, 0~85%RH(no condensation)
Standard accessories
Data line,manual,calibration box SQCX quality management software,Color matching cloud Wechat applet,MOBCCS APP(download from the official website)
Optional Accessories
Mini printer
Multifunctional smart buttons
There are multifunctional smart buttons (the instrument can set parameters and check measurement data)
