CCTV Camera Tester 8MP 4 In 1 5 inch Camera Monitor 4K AHD/CVI/TVI CVBS Analog HDMI VGA Input UTP Cable Test

Product Features

The PEGATAH 8MP 4 In 1 CCTV Tester features a 5-inch 800*480 resolution TFT-LCD display screen, providing clear video monitoring. It supports various camera tests such as AHD, CVI, and TVI, ensuring comprehensive camera testing.
With a 3.6mm lens and 1/3 inch sensor size, this tester offers good imaging performance. It has a maximum IR distance of 10-20m, enabling clear monitoring in low-light environments.
It comes with multiple features like HDMI/VGA input for high-definition video, BNC output for standard color bar, and UTP Cable Test to ensure the integrity of cables. It also has a rechargeable 18650 battery for convenient use.
The PEGATAH CCTV Tester supports different camera protocols such as PELCO-D/P and has adjustable baud rates from 600 to 14400bps. It is compatible with various security cameras and can be used for video surveillance.
It provides DC 12V/1A output for cameras and 1 channel audio signal input, offering comprehensive functionality for CCTV systems. The EU Plug makes it convenient for international use.

Specifications

Brand Name

PEGATAH

Lens

3.6mm

Hign-concerned Chemical

None

Sensor Size

1/3 inch

Maximum IR Distance(m)

10-20m

Sensor Type

CMOS

Model Number

IV8W

Plug Type

EU Plug

Display screen

5.0 inch 800*480 resolution TFT-LCD

AHD camera test

Support 720P/1080P3MP/5MP/8MP

CVI camera test

Support 720P/1080P/3MP/4MP/5MP/8MP

TVI camera test

Support 720P/1080P3MP/5MP/8MP

IPC camera test

Not support

HDMI/VGA input

1920X1080 video input

Video input

1 channel Analog signal input

BNC output

support PAL / NTSC formats standard color bar output

UTP Cable Tester

Support RJ45 cable test

LED lamp

Support

DC 12V/1A output for camera

Support

Audio Input Test

1 channel audio signal input

Power Adapter

DC 5V 1.5A

Battery

Rechargeable 18650 Battery

PTZ Controller

Support RS485

PTZ Protocol

Compatible with protocols PELCO-D/P

Baud Rate

600,1200, 2400, 4800, 9600,14400bps

IP camera input

Not Support

Security Camera Monitor

Video Surveillance

CCTV Display

CCTV Monitor

Description

CCTV Camera Tester 8MP 4 In 1 5 inch Camera Monitor 4K AHD/CVI/TVI CVBS Analog HDMI VGA Input UTP Cable Test
