ESC920H SC/APC Fast Connector for 3.0mm 2.0mm and 0.9mm Indoor Cable Fiber Optic Field Assembly Connection Quick ONU ONT OLT

★ ★ ★ ★ ★
Reviews | Questions & Answers
AU $12.24
Price includes 10% AU GST

Option :
Quantity
In Stock. Ships in 24 hours
Shipping: AU $0.00
Estimated Delivery on -
Secure Payment
Multiple payment options
Customer Service Guarantee
DOA Guarantee Missing/Wrong Items Guarantee Quality Guarantee No Reason Returns
Specifications
Brand Name
IOT OTDR
Item Type
Fast Connector
Wireless function
No
Hign-concerned Chemical
None
Model Number
ESC920H-APC
Cable
3.0mm & 2.0mm Cable & 0.9mm cable
Fiber Diameter
125μm ( 652 & 657 )
Coating Diameter
900μm
Mode
SM
Operation Time
about 1 min(exclude fiber presetting)
Insertion Loss
≤ 0.3 dB(1310nm & 1550nm), Max ≤ 0.5 dB
Return Loss
≥55dB for APC
Success Rate
>98%
Reusable Times
≥5 times
Tighten Strength of Bare Fiber
>3N
Tensile Strength
>50N
Temperature
-40~+85℃
On-line Tensile Strength Test (20 N)
IL ≤ 0.3dB
Mechanical Durability(500 times)
IL ≤ 0.3dB
Drop Test(4m concrete floor, once each direction, three times total)
IL ≤ 0.3dB
Connector Length
45.5mm
semi_Choice
yes
