Lightning Arrester Protector for Walkie-talkie Relay Station CA-35RS CA-23RP Intercom Interphone Repeater 1Pc, surge protector

Product Features

This lightning arrester protector for walkie-talkie relay stations, with a model number of HE3C38, has a frequency range of DC-1000MHz.
It can withstand a power of 400W PEP and has a low loss of ≤0.2dB, providing reliable protection for the equipment.
With a voltage at discharge start of DC350V +-15% and a high-current withstanding capacity, it can effectively protect against lightning surges.
The compact size of 7.5x4.5x2cm makes it easy to install in different locations, providing convenient protection.
With the options of choice and semi-choice, users can select the appropriate type (CA-23RP or CA-35RS) according to their specific requirements.

Specifications

Brand Name

KOQZM

Hign-concerned Chemical

None

Model Number

HE3C38

requency Range

DC-1000MHz

V.S.W.R

≤1.1

Loss

≤0.2dB

Withstand power

400W PEP

Voltage at discharge start

DC350V+-15%

Discharge voltage of shock wave(1 x 40)uS

1,000V

Withstand current of shock wave(1 x 40)uS

6,000A

Repetitive discharge of shock wave(1 x 40)uS

500A

over 500 times

DC350V±20%

Insulating resistance DC 100V

Over 10,000M ohm

Size

7.5x4.5x2cm

Type

CA-23RP or CA-35RS

Package Included

1xCA-35RS or CA-23RP Lightning Arrester

semi_Choice

yes

Description

Lightning Arrester Protector for Walkie-talkie Relay Station CA-35RS CA-23RP Intercom Interphone Repeater 1Pc, surge protector
