Osee Lilmon 5 1000 Nits High-Bright 5.5 inch Touch Screen DSLR Camera Field Monitor Focus Assist 4K HDMI AV Input Camera Monitor portable monitor dslr field monitor

Product Features

This 5.5-inch touch-screen DSLR camera field monitor has a 1000-nit high-brightness display, providing clear and vivid images even in bright environments.
With a 1000:1 contrast ratio and a 400 PPI, it offers high-quality visual performance for accurate focus and image monitoring.
It supports various HDMI input formats, including 4K, UHD, 2K, and FHD, making it suitable for different shooting needs.
Certified with CE, it meets safety and quality standards, ensuring reliable operation.
With features like focus assist, peaking, and de-log, it helps photographers and videographers achieve better results.

Specifications

Brand Name

OSEE

Hign-concerned Chemical

None

Supporting Language

English

Brightness

1000 nits

Contrast

1000:1

Display Screen

5.5"

Plug Type

UK Plug

HDMI Support Format

others

Model Number

Limon 5

Aspect Ratio

16:9

PPI

400

Color Depth

1.06G

Backlight

Level 1-10

Viewing Angle

178x178

Body

Polycarbonate (with aluminum plate built-in)

Weight

212g

Dimensions

144.0mmx88.5mmx24.4mm

Operating Temp

0-40℃

Battery Type

Sony NP-F

Battery In

6.2-16.8V

Battery Out

5.0-8.4V

Consumption

8.1W

Signal Input&Output

HDMI

Signal Format

4K: 4096 x2160p(30/29.97/25/24/23.98) UHD: 3840 x2160p(30/29.97/25/24/23.98) 2K: 2048x1080p(60/59.94/50/30/29.97/25/24/23.98) FHD: 1920x1080p(60/59.94/50/30/29.97/25/24/23.98) 1080i(60/59.94/50) 720p(60/59.94/50) 480i/576i/480p/576p

SD Card Slot

User LUT Upload&Firmware Upgrade (FAT32 format and under 16G size needed)

Audio Jack

3.5mm

Remote Jack

2.5mm (for color calibration)

Volume

Level 0-31

Rotate/Mirror

Screen Rotate (0, 180, auto), Image Rotate (0, 180), Mirror

Aspect

9:16 (Phone), 4:5, 1:1, 4:3 (SD TV), 1.375:1 (Cinema), 16:9 (HD TV), 1.85:1 (Cinema), 2.37:1 (Cinema), custom(1:3 - 3:1)

Safe

Action&Title

Center

Cross/Hollow

Crosshatch

2x2, 3x3 ... 9x9

Anamorphic

1.33 x, 1.4 x, 1.5 x, 1.6 x, 1.8 x, 1.9 x, 2 x with magnify function

Focus Assist

White Red Green Blue B&W background available

Peaking

Intensity 1-10

De-log

EBU Gamma: GAMMA 2.2/GAMMA 2.4/HLG/PQ Gamut: Rec709/Rec2100 DCI Gamma: GAMMA 2.6 Gamut: P3 D65/PCI-P3 Arri Gamma: El160/El200/El250/El320/El400/E500/El640/El800/El1000/El1280/El1600 Gamut: Rec.709/ALEXA Wide Gamut BMD Gamma: BMD Film/BMD 4K Film/BMD 4.6K Film Gamut: BMD 4K Film/BMD 4.6K Film/BMD Pocket 6K Film Canon Gamma: C LOG/C LOG2/C LOG3 Gamut: Rec.709/Canon Cinema/Rec 2100/DCI-P3/DCI-P3plus Fuji Gamma: F-LOG Gamut: Rec.709/F-Gamut Nikon Gamma: N-LOG Gamut: Rec2100 Panasonic Gamma: V-LOG Gamut: Rec.709/V-Gamut RED Gamma: Redlogfilm/Log3G12/Log3G10 Gamut: Rec.709/DRAGONcolor/DRAGONcolor2/REDcolor2/REDcolor3/REDcolor4/REDWideGamut Sony Gamma: S-LOG/S-LOG2/S-LOG3 Gamut: Rec.709/S-Gamut/S-Gamut3/S-Gamut3.Cine/Rec 2100

User LUT

Up to 10 User LUTs (2x2x2 to 65x65x65 3D LUTs) can be uploaded, support LUT intensity adjustment

Audio Meter

Location&opacity adjustable

Multi-scopes

Waveform, histogram, vector scope and audio meter around scaled image

Description

Osee Lilmon 5 1000 Nits High-Bright 5.5 inch Touch Screen DSLR Camera Field Monitor Focus Assist 4K HDMI AV Input Camera Monitor portable monitor dslr field monitor
