JKW58 / PFR-12 Intelligent Reactive Power Autocompensation Controller 380V 50Hz 4/6/8/10/12 Steps Universal for LV Distribution

Reviews | Questions & Answers
AU $98.19
Price includes 10% AU GST

Option :
Quantity
In Stock. Ships in 24 hours
Shipping: AU $0.00
Estimated Delivery on -
Secure Payment
Multiple payment options
Customer Service Guarantee
DOA Guarantee Missing/Wrong Items Guarantee Quality Guarantee No Reason Returns
Specifications
Rated Current
AC 0-5A
Rated Voltage
AC 380V
Rated frequency
50Hz+-5%
Sensitivity
100mA
COS Preset
0.80-0.99. step length 0.01. Factory preset 0.98 input and cutoff time
Input Delay
dynamic state 100ms-30S. Static state 1-250S. Factory preset dynamic s
Overv-oltage protection
230-260V. step length 1V. Return difference 6V reset 240V
Under-voltage protection
180V. return difference 6V
Auto Discriminating Phase
ON/OFF. factory preset ON(Auto discriminating ON)
Reactive threshold
OFF-4-100kvar. factory preset OFF (reactive threshold inefficiency)
CT variation
50/5A-3000/5A. step length 1. factory preset 500/5A
Capacitance capacity
0-99kvar factor preset of each branch 10kvar
