DC 50-250mm Stroke 2-10Inch Electric Linear Actuator 45-230mm/s 200N 20KG Load 12-36V DC High Speed Tubular Electric Motor

Product Features

This DC 50-250mm stroke electric linear actuator has a speed of 45-230mm/s and can bear a load of 20KG, suitable for home appliances.
It has a 12-36V DC voltage and a brush commutation, with a permanent magnet construction for high efficiency.
The tubular motor type and totally enclosed protect feature ensure its stability and durability. The torque can be customized.
With a VDE certification, it meets high-quality standards. The mainland-China origin guarantees production quality.
This electric linear actuator is a reliable solution for various home appliance applications, providing precise movement and control.

Specifications

Brand Name

BRINGSMART

Continuous Current(A)

Output Power

Commutation

Brush

Type

Tubular Motor

Protect Feature

Totally Enclosed

Construction

Permanent Magnet

Usage

Home Appliance

Efficiency

IE 1

Model Number

TGD

Torque

10-200N for customized

Voltage(V)

12-36V DC

Speed(RPM)

45-230mm/s

Stroke

50-300mm

Stroke(inch)

4-10 Inch

Load

10-200N

Load(kg)

Max 20kg

Description

DC 50-250mm Stroke 2-10Inch Electric Linear Actuator 45-230mm/s 200N 20KG Load 12-36V DC High Speed Tubular Electric Motor
