JIMIMAX VL502 obd2 Bluetooth GPS Tracker 4G Canbus Diagnostic OBD Tracking Plug & Play Alarm Locator Google Map APP Car Monitor gps tracker car tracker bluetooth tracker

Product Features

The JIMIMAX VL502 obd2 Bluetooth GPS tracker offers 4G Canbus diagnostic, remote control, and real-time position tracking, suitable for most cars and taxis.
With a battery life of 1 to 4 hours and a compact size of 61*52*26 mm, it is easy to install and use.
It features over-speed alert, geo-fence alert, and history playback with 180 days of data, providing comprehensive vehicle monitoring.
Certified by FCC, it is a reliable and secure device, and comes with a free APP for easy access to tracking information.
It supports multiple OBD protocols and can be connected to different web platforms, making it a versatile and powerful GPS tracker.

Specifications

Brand Name

JIMIMAX

Hign-concerned Chemical

None

Voltage

36V

Battery Life

1 To 4 Hours

Item Size

61*52*26 mm

Special Feature

Remote Control

GPS type

GPS Tracker

Model Name

JM-VL502

Screen Size

No screen

Gps Module

Yes

Out Power

4G Canbus Diagnostic

Yes

Driving Behavior Analysis

Yes

With Bluetooth function

Yes

Data storage

32 + 32 Mb

Over-speed alert

Yes

Geo-fence alert

Yes with 20 Geo-fence

History playback

Yes with 180 days playback

Suit for scooter

yes

Platorm for EU.Middle East countries

eu.tracksolidpro.com

Web Platform for American countries

us.tracksolidpro.com

Web Platform for Asia countries

hk.tracksolidpro.com

Vibration alarm

Yes

Moving alarm

Yes

Real time position

Yes

ACC detection

Yes

Internal 3-axis accelerometer

Yes

OTA upload software remotely

Yes

GPS tracker 4G

Yes

Suit for taxi and Car

Yes

Anti-thieft gps

Yes

GSM/GPS antenna

Built-in GSM antenna, GPS ceramic antenna

Operating temperature

-20℃~+70℃

Standby current

≤5mA

Position accuracy

no more than 2.5m CEP

Communication system

GSM/LTE

Tracking sensitivity

-165dBm

Acquisition sensitivity

-148dBm

TTFF (open sky)

Avg. hot start ≤1sec

Updated of OB22

Yes

Unique design

YES

Quad brand GPS tracker

Yes

Car GPS locator

Yes

Motorcycle gps tracker

Yes

Tracker for motorbike

Yes

Updated of VL04

Yes

Waterproof gps locator

Yes

Free APP

Yes find "TracksolidPro" in app store or google play

GPS Tracker for car

YES

Concox GPS tracker

YES

GPS tracker mini

YES

GPS tracker with battery

YES

SIM card type

2G/4G , Micro-SIM card

See real time position on Google map

Yes by APP and PC

GPS tracker kind

YES

Can fall back to 2G

YES

OBD gps locator

YES

Builti in Battery

Yes 50mAh

Tamper Alert

Yes

Positioning system

GPS+BDS

Frequency

Positioning accuracy

no more than 2.5m CEP

Communication network

GSM/ LTE CAT1

LED indication

GPS (Blue)

Sensors

Accelerometer

Driving behavior analysis

Harsh turn, harsh acceleration, Harsh braking,

Mini Vehicle GNSS Tracker

YES

Multi alerts

low battery, speeding, removal

Connection

OBD II

Wialon platform can be connect

YES

Communication protocol

TCP

Suit for

most car and taxi

gps tracker car

YES

Car gps tracker with relay

Yes optional

4G gps tracker

YES

gps tracking device

Yes

OBD port

K-Line, CAN Bus

Vehicle tracker

Yes

gps location tracker

Yes

GPS tracking for car

Yes

VL502 ( E) version brand

LTE-FDD: B1/B3/B5/B7/B8/B20/B28 GSM: B2/B3/B5/B8

VL502( L) Version brand

LTE-FDD: B2/B3/B4/B5/B7/B8/B28/B66 GSM: B2/B3/B5/B8

LTE Cat 1 Vehicle Tracker

YES

GPS tracking device

Yes

Input voltage

9-36V

OBD protocols

ISO 9141-2 (5 baud init, 10.4 kbaud) ISO 14230-4 KWP (5 baud init, 10.4 kbaud) ISO 14230-4 KWP (fast init, 10.4 kbaud) ISO 15765-4 CAN (11 bit ID, 250 kbaud) ISO 15765-4 CAN (11 bit ID, 500 kbaud) ISO 15765-4 CAN (29 bit ID, 250 kbaud) ISO 15765-4 CAN (29 bit ID, 500 kbaud) SAE J1939 CAN(29bit ID, 250kbaud) SAE J1939 CAN(29bit ID, 500kbaud)

Diagnostic fuel

Yes suit for most car, you can info your car model in advance

Support the Arabic language

YES

Description

JIMIMAX VL502 obd2 Bluetooth GPS Tracker 4G Canbus Diagnostic OBD Tracking Plug & Play Alarm Locator Google Map APP Car Monitor gps tracker car tracker bluetooth tracker
