External Testing Certification
ce
Model Name
Autel IM508 IM508Pro
Item Type
Auto Key Programmer
Operating System
AndroidTM 4.4.2, KitKat
Processor
Cortex-A9 processor (1.6 GHz)
Display
7-inch LCD capacitive touchscreen with 1024x600 resolution
Connectivity
Mini USB 2.0 USB 2.0 Wi-Fi
Connectivity 2
Micro SD card (supports up to 32GB)
Sensors
Ambient light sensor for brightness auto changing
Audio Input/Output
Input: N/A Output: buzzer
Power and Battery
3.7 V/5000 mAh lithium-polymer battery
Power and Battery 2
Charges via 5 VDC power supply
Dimensions (W x H x D)
300 mmx 220 mm x 50 mm
Weight
NW 1.42 kg GW 8.655 kg
Protocols
ISO9141-2,ISO14230-2,ISO15765
Protocols 1
Highspeed,Middlespeed,Lowspeed and Singlewire CAN
Protocols 2
SAE-J1850 PWM,CAN ISO 11898,Highspeed
Protocols 3
Middlespeed,Lowspeed and Singlewire CAN
Protocols 4
fault-tolerant CAN SAE J2610,GM UART,UART Echo Byte Protocol
Protocols 5
Honda Diag-H Protocol, TP2.0, TP1.6
Feature
XP200 key programmer
Type
scaner automotriz profesional
GOOd
batter than launch x431 pro
Tested Battery Life
Around 4.5 hours of continuous use
Battery Charging Input
5 V/1.5 A
Power Consumption
500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V
Operating Humidity
5% - 95% non-condensing
Supported System
ABS, DPF, EPB, SAS, SRS, TPMS, Engine, Transmission, BMS
Supported System 2
Oil Reset, BMS, Seats, Injector, Suspension, Throttle
Supported System 3
lmmo Keys, WIN DR POOF, Brake bleed
Supported System 4
IMMO Key Programming, advanced key learning
Supported System 5
IMMO ECU reset/adaptation, refresh/coding
Supported System 6
key generation, EEPROM/MCU read/write
Accessories
Adapter Cable, Carrying Case, USB Cable, User Guide
Features 1
Backlit Display, Built-In Battery
Features 2
Check Engine Light Shut Off, Erases Codes
Features 3
Freeze Frame Displays, Internet Updateable
Features 4
LCD Display, Multi-Language Interface
Features 5
User Friendly, Color Display
Multi-Language 1
English, Spanish, Russian, Portuguese, Italian,Polish
Multi-Language 2
Japanese, Korean, German, Swedish,Turkish,Vietnamese,Arabic,Thai
Similar Item
Autel MaxiIM IM608,IM608PRO
Model
Autel MaxiIM IM508 IM508PRO
Software Update
2 Years Free Update
