Autel MaxiIM IM508S XP400 PRO Car Key Programming Tool OBD2 Scanner IMMO Key Programmer Diagnostic Auto Scanner PK KM100 IM508

Product Features

The Autel MaxiIM IM508S is equipped with a 7-inch LCD capacitive touchscreen and offers a 1024x600 resolution, providing clear and intuitive operation. It also has a backlit display for easy use in various lighting conditions.
With 4GB RAM and 64GB on-board memory, along with an Android 11 operating system and a powerful Rockchip RK3566 Quad core processor (4x 1.8GHz(A55)), it ensures smooth performance and quick access to various functions.
This car key programming tool supports multiple protocols such as ISO9141-2, ISO14230-2, etc., and can perform IMMO key programming, advanced key learning, and other operations. It is very versatile.
It comes with a 3.7 V/5000 mAh lithium-polymer battery that can provide around 4.5 hours of continuous use. It also charges via a 5 VDC power supply, making it convenient to use.
The Autel MaxiIM IM508S offers a variety of features like checking engine light shut off, erasing codes, freeze frame displays, and is internet updateable. It is a comprehensive and user-friendly tool.

Specifications

Brand Name

Autel

Hign-concerned Chemical

None

Is Batteries Included

Yes

External Testing Certification

Material

plastic

Hardware Version

Autel 2025 Newest

Item Length

Item Type

Auto Key Programmer

Special Features

Wifi

Software Version

Autel 2025 Newest

Item Width

Model Name

Autel MaxiIM IM508S PK IM508

Item Height

Item Weight

5.1

Voltage

12 V (9-24 V)

Electronic

Yes

Power (W)

7.5 W

Brand

Autel

Name

Autel IM508S

Operating System

Android 11

Processor

Rockchip RK3566 Quad core, 4x 1.8GHz(A55)

Memory

4GB RAM & 64GB On-board Memory

Display

7-inch LCD capacitive touchscreen with 1024x600 resolution

Connectivity

Mini USB 2.0 USB 2.0 Wi-Fi

Connectivity 2

Micro SD card (supports up to 32GB)

Sensors

Ambient light sensor for brightness auto changing

Audio Input/Output

Input: N/A Output: buzzer

Power and Battery

3.7 V/5000 mAh lithium-polymer battery

Power and Battery 2

Charges via 5 VDC power supply

Operating Temp

0 to 50°C

Storage Temp

-20 to 60°C

Dimensions (W x H x D)

300 mmx 220 mm x 50 mm

Weight

NW 1.42 kg GW 8.655 kg

Protocols

ISO9141-2,ISO14230-2,ISO15765

Protocols 1

Highspeed,Middlespeed,Lowspeed and Singlewire CAN

Protocols 2

SAE-J1850 PWM,CAN ISO 11898,Highspeed

Protocols 3

Middlespeed,Lowspeed and Singlewire CAN

Protocols 4

fault-tolerant CAN SAE J2610,GM UART,UART Echo Byte Protocol

Protocols 5

Honda Diag-H Protocol, TP2.0, TP1.6

Feature

XP200 key programmer

Fuction

Car Scanner

Effect

Car diagnostic

interface

Obd2

Type

scaner automotriz profesional

GOOd

batter than launch x431 pro

Tested Battery Life

Around 4.5 hours of continuous use

Battery Charging Input

5 V/1.5 A

Power Consumption

500 mA (LCD on with default brightness, Wi-Fi on) @3.7 V

Operating Humidity

5% - 95% non-condensing

Supported System

ABS, DPF, EPB, SAS, SRS, TPMS, Engine, Transmission, BMS

Supported System 2

Oil Reset, BMS, Seats, Injector, Suspension, Throttle

Supported System 3

lmmo Keys, WIN DR POOF, Brake bleed

Supported System 4

IMMO Key Programming, advanced key learning

Supported System 5

IMMO ECU reset/adaptation, refresh/coding

Supported System 6

key generation, EEPROM/MCU read/write

Accessories

Adapter Cable, Carrying Case, USB Cable, User Guide

Features 1

Backlit Display, Built-In Battery

Features 2

Check Engine Light Shut Off, Erases Codes

Features 3

Freeze Frame Displays, Internet Updateable

Features 4

LCD Display, Multi-Language Interface

Features 5

User Friendly, Color Display

Multi-Language 1

English, Spanish, Russian, Portuguese, Italian,Polish

Multi-Language 2

Japanese, Korean, German, Swedish,Turkish,Vietnamese,Arabic,Thai
